product List

---

• 1 changeover contact or 1 normally open contact
• Ultra-slim, 5mm wide
• Sensitive DC coil – 170 mW (possibility of AC/DC power supply with 93 Series sockets)
• UL Listing (relay/socket/jumper link)
• Cadmium-free contacts
• 8/8 mm clearance/sliding distance
• 6 kV (1.2/50 μs) insulation between coil and contacts

• AC or DC coil
• Lockable test button option and mechanical indicator as standard
• Variant with LED and integrated protection circuit
• Sockets Series 94 for printed circuit board, solder or for 35mm rail mount (EN 60715) with push-in, screw or screwless terminals
• 99 Series coil indication and EMC suppression modules and Type 86.30 timer modules
• Adaptors for alternative mount available
• UL Listing (relay/socket/jumper link)
• Cadmium-free contacts
• Contact material options
• European patent

• Very low acoustic noise
• Minimal depth within enclosure
• Air volume (14…470) m³/h (with Exhaust Filter installed in cabinet)
• Air volume (24…630) m³/h (free flow)
• Operating voltage: 24 V DC, 120 V AC, 230 V AC

For More Reference Please Visit Page No.50

• Output Voltage - 24V
• Output Current -  6.25A
• Household appliance approvals according to IEC/EN 60335-1, IEC/EN 61558-1 and IEC/EN 61558-2-16
• AC input voltage range selectable by switch (90-132Vac, 180-264Vac)
• No load power consumption < 0.5W
• Low profile design: 30mm height
• OVC III, Pollution Degree 3
• Wide operating temp -30°C ~ 70°C (Support -40°C cold start)
• Conforms to harmonic current IEC/EN 61000-3-2, Class A
• High MTBF > 700,000 hrs per Telcordia SR-332
• Compliance with SEMI-F47

 Finger type Busbar Support offers versatile solution for higher short circuit rating and can hold Single Run to Multiple Runs of 6.0mm, 10mm & 12mm Busbars.

• Threads Available- Metric, PG & Combination (PG-Metric)
• Thread Sizes- M12 to M63, PG7 to PG48 & PG7M12 to PG48M63
• Thread Length- Standard & Long
• Temperature Range- -40°C / +100°C
• Flammability Rating- UL94-V2
• Sealing Ring & O-Ring- Nitrile Buna Rubber (NBR)
• Certifications- UL, RoHS, CE, IP68
• Accessories- Screw Plug, Blanking Plug, Dust Cap, Locknut
•  Silver Grey, Light Grey and Black color.

power contactor, AC-3e/AC-3, 9 A, 4 kW / 400 V, 3-pole, 230 V AC, 50/60 Hz, auxiliary contacts: 1 NO, screw terminal, size: S00
